Ledium FOKUS XL1 24V 10W 1020 lm, 30°, CCT LED recessed light, 2700K-5000K tunable, CRI90 for PWM dimming / Loxone / smarthome

This 24V recessed LED light for smarthome systems was developed by Ledium Ltd., and it is in mass production.
Made in Europe.

The increasingly widespread smart home systems (e.g. Loxone) already have circadian rhythm color temperature control by default.
For these smart home LED brightness and color temperature control systems, we have developed the LEDIUM FOKUS 24V lamp family.
The 10W power and the 1020 lm luminous flux make it suitable for general lighting. Perfect solution for lighting offices, apartments, hotel premises.

The lamp contains LED modules with 2700K and 5000K color temperature Samsunkg chips, and CRI>90 color rendition, which can be controlled by any 24V common anode PWM LED controller.

ATTENTION!
It is FORBIDDEN to operate the two LED channels simultaneously at full brightness because it will cause the LED lamp to overheat and malfunctio.. The warranty does not cover such issue. Always follow the instructions for LED controllers.
CCT LED controllers adjust the desired color temperature by varying the ratio of the hot and cold white LEDs, so that only one channel can operate at 100% brightness at all times.
The lamp can also be used using only one of the LED channels in monochrome mode, in which case only the red (+) and desired color wires need to be connected.

It can NOT be connected directly to 230V mains!
Cable marking:
24V (+) : red
2700K (-) : white
5000K (-) : black

IP rating: IP20, for indoor use.
